RATTLE NOISE FROM UNDER THE VEHICLE
TECHNICAL SERVICE BULLETIN
Reference Number(s): JLRTB02065NAS1, Date of Issue:
January 06, 2021
| LAND ROVER: | Discovery/L462; Range Rover/L405; Range Rover Sport/L494 |
| SECTION: | 501-02 |
MARKETS
NORTH AMERICA
CONDITION SUMMARY
SITUATION:
A rattling noise can be heard coming from under the vehicle. Investigation has determined that the rattle is coming from the engine undershield.
CAUSE:
Star washer relaxation.
ACTION:
Follow the instructions below.
PARTS
NOTE:
LR003643 contains 25 nuts, only 6 nuts are required for each repair.
PARTS INFORMATION
| PART NUMBER | DESCRIPTION | QUANTITY |
|---|---|---|
| LR003643 | Nuts | 1 |
WARRANTY
NOTE:
- Repair procedures are under constant review, and therefore times are subject to change; those quoted here must be taken as guidance only. Use TOPIx to obtain the latest repair time.
- The JLR claims submission system requires the use of causal part numbers. Labor only claims must show the causal part number with a quantity of zero.
WARRANTY INFORMATION
| DESCRIPTION | SRO | TIME (HOURS) | CONDITION CODE | CAUSAL PART |
|---|---|---|---|---|
| JLRTB02065 - Renew engine undershield fixings | 99.01.41 | 0.3 | GD | LR064187/LR133837 |
NOTE:
Normal Warranty procedures apply.
SERVICE INSTRUCTION
- Remove the engine undershield (see TOPIx Workshop Manual section 501-02: Front End Body Panels - Removal and Installation - Engine Undershield).
Remove and discard the 6 star washers.
Install the 6 new nuts.
- Torque: 3 Nm
- Install the engine undershield (see TOPIx Workshop Manual section 501-02: Front End Body Panels - Removal and Installation - Engine Undershield).
